Extended Warranty Coverage
Warranty Package Coverage Includes:
Extension of John Deere factory comprehensive warranty for labor, and repair or replacement parts in the event your covered product fails to operate as a result of a mechanical or electrical failure caused by defects in workmanship and/or materials. At our discretion, replacement parts used in covered repairs will be either new Genuine John Deere parts or Genuine John Deere remanufactured parts or components furnished by John Deere. Free pickup and Delivery within a twenty five mile radius.
Warranty Package Coverage Does Not Include:
1) Any product used in a commercial setting or rental basis.
2) Any services not authorized by the administrator or performed by an unauthorized servicer.
3) Any Additional costs for services not specifically covered by this Agreement.
4) Incidental, consequential, or secondary damages or delay in rendering service under this Agreement or loss of use during the period that the covered product is at an authorized service center or otherwise awaiting parts.
5) Transportation, parts, or repair due to normal wear and tear and items normally designed to be periodically replaced by the purchaser during the covered product’s life, including but not limited to blades, belts, batteries, light bulbs, hoses, etc.; loss or damage caused by war, invasion, or act of foreign enemy, hostilities, civil war, rebellion, riot, strike, labor disturbances, lockout, or civil commotion; damage from accident, abuse, misuse, mishandling, introduction of foreign objects into the covered product, failure to follow the manufacturer’s instructions, and external causes including third party actions, fire, theft, insects, animals, exposure to weather conditions, lightning, windstorm, sand, dirt, hail, earthquake, flood, water, acts of God or consequential loss of any nature.
6) Nonfunctional or aesthetic parts, including but not limited to plastic parts, knobs, rollers, baskets, scratches, peeling, and dents.
7) Accessories or attachments used in conjunction with a covered product, other than mower decks used on lawn tractors, lawn and garden tractors, and commercial mowers.
8) Service where no problem can be found.
9) Breakdowns that are not reported within the terms of this Agreement.
Maintenance Plan
Maintenance Package Includes:
Worry free maintenance plan, complete service, free pickup and delivery within a twenty five mile radius.
Maintenance plan includes services listed below:
1) Change Engine Oil and Filter
2) Change Air Filter and Pre-Cleaner
3) Change Spark Plugs
4) Change Fuel Filter
5) Check Transmission Oil, if applicable
6) Check Engine Coolant, if applicable
7) Change Hydraulic Filter
8) Sharpen Blades
9) Check Safety Systems
10) Level Mower Deck
11) Check and Adjust Tire Pressure
12) Check Wheel Bolts
13) Check and Tighten Loose Hardware
14) Check Engine Cooling Fins
15) Check Battery
16) Check Electrolyte Level and Battery Voltage
17) Clean Radiator Fins and Air Intake Screens
18) Clean Under Mower Deck
19) Lubricate Front Axle Pivot
20) Lubricate Front Spindles
21) Lubricate Front Wheel Bearings
22) Lubricate Mower Spindles
23) Lubricate Mower Gage Wheels
24) Check Belts and Mower Adjustments
We will provide transportation, labor, and repair or replacement parts in the event your covered product fails to operate as a result of a mechanical or electrical failure caused by defects in workmanship and/or materials. At our discretion, replacement parts used in covered repairs will be either new Genuine John Deere parts or Genuine John Deere remanufactured parts or components furnished by John Deere.
Maintenance Coverage Does Not Include:
1) Any services not authorized by the administrator or performed by an unauthorized servicer.
2) Any Additional costs for services not specifically covered by this Agreement.
4) Incidental, consequential, or secondary damages or delay in rendering service under this Agreement or loss of use during the period that the covered product is at an authorized service center or otherwise awaiting parts.
5) Transportation, parts, or repair due to normal wear and tear and items normally designed to be periodically replaced by the purchaser during the covered product’s life, including but not limited to blades, belts, batteries, light bulbs, hoses, etc.; loss or damage caused by war, invasion, or act of foreign enemy, hostilities, civil war, rebellion, riot, strike, labor disturbances, lockout, or civil commotion; damage from accident, abuse, misuse, mishandling, introduction of foreign objects into the covered product, failure to follow the manufacturer’s instructions, and external causes including third party actions, fire, theft, insects, animals, exposure to weather conditions, lightning, windstorm, sand, dirt, hail, earthquake, flood, water, acts of God or consequential loss of any nature.
6) Nonfunctional or aesthetic parts, including but not limited to plastic parts, knobs, rollers, baskets, scratches, peeling, and dents.
7) Accessories or attachments used in conjunction with a covered product, other than mower decks used on lawn tractors, lawn and garden tractors, and commercial mowers.
8) Service where no problem can be found.
Engine is powerful and smooth-running V-twin design

A 24-hp (17.9-kW) V-twin extended-life series (ELS) engine provides plenty of power and torque to handle tough mowing, mulching, and bagging:
- Includes ELS engine features for enhanced performance and longer life
- V-twin cylinder design for greater torque, lower vibration, and improved sound quality
- Electronic ignition for fast starts
- Spring-return feature to ensure the operator will not mistakenly leave the throttle lever in the choke position
- Cast-iron cylinder liners for longer engine life
- Overhead valves for excellent power and fuel economy
- Full-pressure lubrication and oil filter for cleaner oil, prolonging engine life and extending the time between oil changes
- More effective when operating the tractor on an incline
Fuel tank

- The capacity is 2.4 U.S. gal. (9.1 L).
- The fuel filler opening is conveniently located under the seat.
- Filling the tank without spilling is easy.
- A tethered fuel tank cap is more convenient.
- The sealed fuel cap helps keep vapors inside the tank.
John Deere Easy Change™ 30-second oil change system

The John Deere Easy Change 30-second oil change system makes changing the engine oil easy, quick, and clean. Changing the oil is as easy as twisting on a new oil-filled filter. Oil does not need to be drained from the engine.
The John Deere Easy Change filter is an additional engine oil reservoir. Changing the filter removes the captured contaminants and replaces about 0.8 qt (0.76 L) of engine oil.
The functionality does not stop with ease of use. The Easy Change oil system has several meaningful benefits over the traditional oil filter system of the 100 Series:
- A synthetic filter material is used for more predictable filtering and longer life.
- Filtering capacity is greater than with a standard oil filter.
- More filter surface area
- More oil flow capacity
- The system has 40 percent more oil volume.
- The oil and engine run cooler.
- The oil filter valve closes whenever the engine stops, so filtered particles are captured and cannot drain back into the engine.
- The risk of spilling during oil service is greatly reduced.
- Waste oil (and new oil production) is reduced by over 1,000,000 lb (453,592.4 kg) per tractor production year.
- This system is not a compromise to just make oil changes easier—these engines pass the same John Deere expectations and rigorous testing as always.
Partly due to these improvements, it is not necessary to remove and dispose of all the oil in the engine during service.
Everyone who uses the John Deere Easy Change system saves time and avoids the mess of a traditional oil change. In the past, many 100 Series Lawn Tractor owners rarely or never got around to changing their engine oil. With the 30-second oil change, even people who previously would not consider changing the oil themselves can easily do it. The Easy Change system is a no-mess, no-fuss solution the competition cannot match.
Installation instructions are in the Operator’s Manual and in the John Deere Easy Change service part box.
Please recycle. Many local government recycling programs, authorized retailers, auto-service centers, and auto-parts stores will puncture and recycle used oil filters and oil.
Full-featured engine is more reliable and lasts longer

This full-featured engine is engineered to deliver world-class endurance and power. A step above the competition, it is designed to be more dependable and longer lasting, saving time and money over the long run.
Built to exceed demanding needs by incorporating premium features and innovative designs:
- Overhead valve (OHV) design for cooler operation and longer valve life
- Contains an advanced debris management system that directs cooling air through the rotating screen to the air cleaner compartment, where large debris is pre-filtered through ejector slots
- Keeps unfiltered air out of the engine through a large, dual-sealed, premium oval-shaped cartridge-style filter
- Ensures maximum protection for extended engine life with the premium air cleaner, a pleated paper filter with a foam precleaner
- Captures fine particles for maximum protection and extended maintenance
- Provides maximum protection with full-pressure lubrication system
- Pumps oil by a mechanical gerotor-style pump to all critical engine components
- A premium bearing package for improved durability; includes a super-finished crank pin bearing with a 50 percent smoother surface to increase load capacity by 35 percent
- Uses a premium DU Teflon®-coated bearing
- Helps resist wear and increases durability through self-lubricating bronze bearing
- Wear-resistant, chrome-plated valve stems for long-life valves
- 44 percent smoother for longer life
- Cast-iron cylinder liners for longer life
- Dependable float-feed type carburetor with integral fuel pump
- High-capacity fuel filter for dependable operation
- John Deere Easy Change™ 30-second oil change system makes changing the engine oil easy, quick, and clean
- Maintenance-free electronic ignition for quick, dependable starts
- Platinum spark plugs for extended life
Teflon is a trademark of The Chemours Company FC, LLC.
Frame made of full-length welded steel for reliability


The solid one-piece frame is constructed of 12-gauge, 0.105-in. (2.66-mm) steel:
- Full-length, robotically welded frame design has high-strength steel rails for added strength and long life.
- One-piece, steel fender deck is bolted to the frame.
Cast-iron front axle will not bend

The front axle is constructed of solid cast iron that will not bend:
- Automotive-like steering system with sector and pinion steering gears and single drag link with a tie rod provides a very strong, low-effort, and tight-turning system.
- Three grease fittings, on both steering spindles and center pivot, allow for regular lubrication to help maintain easy steering and minimize wear.
- Large, 0.75-in. (1.9-cm) diameter wheel spindles provide excellent durability.
Front bumper protects the tractor


The front bumper is included on the S130, S140, S160, S170, and S180. It is available as an optional attachment for the S100, S110, and S120.
- Additional front-end protection
- Attractive, bold style
CargO Mount™ system makes installation of rear bagger and other attachments easy




The CargO Mount system is a combination of front- and rear-mounting points providing convenient and easy installation of the sun canopy, rear bagger, and other attachments.
Snow removal is a strength of lawn tractors


An advantage of lawn tractors is their ability to use equipment for snow removal. Lawn tractor owners can add a John Deere snow blower or front blade to make quick work of moving snow whenever the need arises. Weather enclosure and tire-chain attachments add comfort and performance.
Equipment available for snow removal includes:
- 44-in. (112-cm) Snow Blower
- 46-in. (117-cm) Front Blade
- Tire chains or TerraGrip traction belts
- Weather enclosure
- Weights
Hydrostatic transmission gives an infinite choice of ground speeds


A Kanzaki® Tuff Torq® hydrostatic transmission gives an infinite choice of speeds and makes changing the direction of travel easy. Side-by-side foot pedals control the speed and direction of travel:
- Automotive-type accelerator controls ensure easy operation.
- Operator can change direction without lifting foot off the platform.
- Large pedal surface gives superior operator comfort.

Appropriate transmissions are used in each model, depending on rear tire size and tractor performance requirements, to ensure excellent performance and reliability:
- Tuff Torq TLT200 – S100, S110, S120, S130, S140, and S160
- Tuff Torq K46 – S170 and S180
Kanzaki and Tuff Torq are trademarks of Kanzaki Kokyukoki Mfg. Co., Ltd.
Operator station designed for comfortable operation


The operator station is designed for operator comfort and easy operation:
- Controls are positioned where they are easy to reach and use to control the tractor.
- The steering wheel is positioned and angled to give the operator plenty of room and steering comfort.
- The seat is positioned to provide the most comfortable operator position.


Controls are easy to see and use:
- A deluxe, 14-in. (35.6-cm) steering wheel provides greater operator comfort and control.
- Ignition switch is on the dash for starting ease.
Wide footrest areas with non-slip, anti-vibration rubber floor mats are provided for operator comfort:
- The wide footrest makes it easy to step over the mower deck while entering or exiting the seat.
- Debris removing channels help keep the footrest area clean and dry.




Operator comfort is enhanced with a 15-in. (38-cm) high-back, two-piece seat with an open back:
- Especially helpful when operating the tractor for extended periods of time
- Easily adjusted forward or rearward while in the seat
- Seat travel of 5.5 in. (14 cm) and 10 different positions to adjust for operator height


Two long seat springs give plenty of seat travel to smooth out the ride, keeping the operator comfortable while operating the tractor.
The seat can be tilted forward for protection from the elements and to provide easy access to the fuel tank.


A beverage holder and storage compartment, located on the right fender, are conveniently located and easy to use.

Fender flares cover the tires more completely and add style to the tractor. Handgrips give extra comfort for the operator, especially when operating on hillsides. Reflectors make the tractor more visible.
Easy-read fuel gauge shows fuel level on dashboard and controls are convenient to use


Instruments and controls
The contoured dash has clean, attractive styling:
- Controls are color-coded and labeled for easy identification.
- Controls are logically placed and easy to reach.
- The hour meter makes it easy to tell when oil changes and other maintenance should be performed.
- Functional design of the controls provides good appearance and a comfortable feel.
Easy-read fuel gauge shows fuel level on the dashboard


The easy-read fuel gauge shows how much fuel is in the tank and can be seen on the dashboard:
- Easy to check fuel level
- Convenient location
- Visible in cloudy or dusk conditions (is not backlit)
- Does not slosh from bumps
- The MowerPlus™ smartphone app can read and remember the fuel level (optional MowerPlus deluxe smart connector required)
- The hour meter is also visible on the fuel gauge display
Side-by-side transmission control pedals


Side-by-side foot pedals control the speed and direction of travel:
- Automotive-type accelerator controls ensure easy operation.
- Operator can change direction without lifting foot off the platform.
- Large pedal surface gives superior operator comfort.
Cruise control (S120, S130, S160, S170, and S180)

Cruise control is available on the S120, S130, S160, S170, and the S180:
- To engage, lift the cruise lever and hold until the foot is removed from the forward pedal.
- The cruise control can be released by pushing on the brake pedal or the forward pedal.
Mower deck height adjustment

A spring-assisted, ergonomically designed lift lever simplifies adjusting the mower cut height:
- Increments of 1/4 in. (0.64 cm) allow fine-tuning the cut height.
- Cut height is adjustable from 1 to 4 in. (2.5 to 10.2 cm).
- The lift handle is shaped for easy use and is out of the way of entering or exiting operators.
Parking brake control


The parking brake control is conveniently located on the tractor pedestal for easy access. It holds the brake pedal securely in the locked position.
Electric power take-off (PTO) clutch is easy and convenient

The heavy-duty electric PTO clutch is operated with a convenient dash-mounted switch.
Reverse implement option (RIO)

Using RIO
CAUTION: Children or bystanders may be injured by rotating blades. Before traveling forward or rearward:
- Carefully check the area around the machine.
- Disengage the mower before backing up.
NOTE: Backing up while the mower is engaged is strongly discouraged. RIO should be used only when operating another attachment or when the operator deems it necessary to reposition the machine with the mower engaged.
- Stop forward travel.
- Look behind the machine to be sure there are no bystanders.
- Push and hold in the RIO switch while depressing the reverse pedal slightly.
NOTE: If the engine and mower or other attachment stops while repositioning the machine, return the attachment engagement lever/switch to the off position. Start the engine and engage mower or other attachment. Begin again with step 2.
- Release the RIO switch and reposition the machine as the machine begins to move rearward.
- Resume forward travel. The mower or other attachment should continue operating.
- Repeat procedure to position the machine again.
Convenient maintenance is supported by trusted self-service resources

John Deere riding lawn mowers are equipped with a QR code label that links to an owner support website. The label can be found on the rear fender, to the left of the seat.


The owner support website is formatted for smart phones and available without setting up an account and password. The QR code includes the mower’s serial number, enabling the owner support website to provide a maintenance schedule, service parts, attachments, how-to guide, videos, warranty information, and an operator’s manual for the specific mower.
The owner support website also allows users to purchase service parts, schedule dealer service, purchase extended warranties, and download the Equipment Mobile app. The Equipment Mobile app enables users to maintain a shared digital service record with their dealer.
Serviceability is convenient with an easy-open hood


The one-piece hood opens easily to permit checking and servicing the engine:
- Important service points are located within easy reach.
- A service-interval decal is provided inside the tractor hood for convenience when servicing the tractor.


The John Deere Easy Change 30-second oil change system makes changing the engine oil easy, quick, and clean. Changing the oil is as easy as removing the old oil-filled filter and twisting on a new oil-filled filter.
The seat tilts up and out of the way to make adding fuel easy.
Hood will not rust or dent and includes quality headlights

- Molded-in color material reduces sound and will not rust or dent.
- Same quality hood material as on larger John Deere tractors provides good resilience and UV resistance for an extended time.
- Openings on the side let in plenty of cooling air while keeping the sound level low.
- Two headlights provide good lighting for nighttime operation.
Help maintain your mower and lawn with the MowerPlus™ app and connector


Overview
Keep a mower running its best and know how it mows with the John Deere MowerPlus app. Simply scan the mower’s barcode to get custom information about the mower.
Benefits
- Engine hours, fuel level, and battery health (as compatible)
- Mowing history with time, distance, area, and speed
- Current day and five-day weather forecast based on location
- Walk-through setup guides
- Expert mowing tips
- Useful attachments for future purchase
- Periodic maintenance reminders
- Safety instructions
To download the free MowerPlus app, visit the Apple® App Store® or Google Play™ store.
Additional details
MowerPlus connectors (sold separately)

MowerPlus connectors are available to transmit vehicle information to the MowerPlus app.
BUC10929 MowerPlus Deluxe Smart Connector is for use with:
- All S120, S130, S160, S170, and S180 Tractors
- Model year 2021 and newer S240 Tractors (serial number 880,001-)
- Model year 2021 and newer Z515E, Z530M, Z530R, and Z545R (serial number 010,001-)
BUC10537 MowerPlus Smart Connector is for use with:
- Model year 2016 and newer Select Series X300 and X500 Tractors
MowerPlus connectors transmit the fuel level and engine hour information to the app, making it easy to keep track of fuel level and maintenance intervals.
MowerPlus connectors require the MowerPlus app on a mobile device to use. The John Deere MowerPlus app and operating system requirements can be found in the mobile device’s app store. The MowerPlus app is only available in the English language, and it is not available in all countries.
Apple and App Store are trademarks of Apple, Inc. Google Play and Android are trademarks of Google LLC. iOS is a trademark of Cisco Technology, Inc. used under license by Apple Inc.
The Edge™ cutting system gives superior performance

The Edge cutting system has been trademarked to emphasize the advantages of the John Deere mower deck designs. They give superior mowing performance, convenience, and reliability:
- The deep deck design lifts grass for a clean, even cut.
- The smooth underside has no nooks and crannies, preventing grass buildup and evenly dispersing grass clippings.
- The rolled outer edge of the deck provides extra strength and protection.
- Dual-stage E-coat and powder paint coatings provide extra protection from rust.
- Flexible discharge chute minimizes property and mower deck damage.
The 48-in. (122-cm) Edge Mower Deck is a three-spindle design with heavy-duty characteristics:
- The 12-gauge, 0.105-in. (2.7-mm) steel deck provides years of dependable mowing.
- Included three-in-one blades work well for side-discharge, mulching, or bagging.
- The blade-to-spindle design provides a unique mounting system for the mower blade that gives extra safety and convenience.
- Four mower deck wheels are standard equipment for a smooth mowing job in rolling terrain.
- No tools are required to switch from mulching to side discharge to rear bagging.
- A mulching cover is an optional attachment that can be installed without the use of tools.
- High-performance mulching blades are available to enhance mulching performance.
Mower wash port


A wash port is provided to make cleaning the underside of the mower deck easy:
-
A hose connector is included with mower deck.
StarLock™ blade design

The StarLock blade design keeps the blade bolt at the correct torque for easy removal.
Optional blades for difficult mulching or bagging conditions are available.
Optional bagger

A cut-and-throw, 6.5-bu (229-L) bagger is sold separately and comes with bagging blades. Special bagging blades are not required but they can enhance performance.
The bagger kit provides an efficient means of collecting grass clippings and leaves. It can be set up without tools in minutes and has easy-to-empty bags.
Two-year or 120-hour bumper-to-bumper warranty is included
A 2-year or 120-hour single-source, bumper-to-bumper warranty* is included for all John Deere 100 Series Tractors.
- The warranty is hassle free, with both the mower and the engine covered by a single warranty.
- If the mower is sold, the remaining warranty term is transferable to a new owner.
*Term limited to years or hours used, whichever comes first, and varies by model. U.S. and Canada only. See the LIMITED WARRANTY FOR NEW JOHN DEERE TURF AND UTILITY EQUIPMENT at JohnDeere.com or JohnDeere.ca/TUWarranty for details.
